Al Code Label Printer Applicator

Flexible High-Speed Print & Apply Labeling

The Al Code Printer Applicator is a versatile industrial print-and-apply labeling system designed to print and automatically apply pressure-sensitive labels directly to products, packages, cases, containers, and other materials.

Designed for demanding production and packaging environments, the Al Code platform combines thermal-transfer printing, pneumatic label application, and configurable application methods to create a solution that can be adapted to a wide range of production requirements.

Whether your application requires a barcode, product identification label, lot number, production date, serial number, or other variable information, the ALcode can print the required data in real time and apply the label as products move through the production process.

The Al Code can be configured to apply labels to both stationary and moving products, including high-speed applications.

Real-Time Printing & Automatic Label Application

Print-and-apply technology combines two critical production processes into one automated system.

Product Data → Print Label → Apply Label → Scan & Verify

Instead of manually printing labels and applying them separately, the ALcode can print variable information on demand and automatically apply the completed label to the product.

This makes the system suitable for applications involving:

• Product identification
• Barcode labeling
• 2D barcode labeling
• QR codes
• Serial numbers
• Lot and batch numbers
• Production dates
• Best-before dates
• Shipping information
• Customer-specific information
• Traceability data

Multiple Application Methods

One of the primary advantages of the Al Code platform is its range of available label application configurations. The appropriate system can be selected based on the product shape, production speed, label size, application position, and available space on the production line.

Available application methods include:

These configurations allow the Al Code to be adapted for a broad range of industrial labeling challenges.

Designed for Industrial Production Lines

The Al Code integrates mechanical, pneumatic, and electronic components into a print-and-apply system designed for industrial production environments.

The platform can be incorporated into new or existing production lines and configured around the specific requirements of the application. Depending on the configuration, the system can label products moving on conveyors, stationary products, cases, cartons, packaging, and other materials.

Typical applications include:

Configurable Thermal-Transfer Printing

The Al Code platform can be equipped with compatible industrial thermal-transfer print engines. Depending on the selected configuration, available print widths, resolutions, and speeds can vary.

Available configurations have included print resolutions of 200 and 300 dpi and industrial print engines supporting a range of label widths and production speeds. IBC can help select the appropriate printing configuration based on the label size, print quality, variable data requirements, and required throughput.

This flexibility makes the ALcode suitable for printing:

• High-quality barcodes
• 2D Data Matrix codes
• QR codes
• Variable text
• Product information
• Sequential numbering
• Serialized labels
• Lot and batch information

Production Speed

The Al Code can support production speeds of up to approximately 100 labels per minute, depending on factors such as the label dimensions, print requirements, product handling, and selected applicator configuration.

Because every automated labeling application is different, IBC can evaluate your specific production line before recommending a configuration.

Factors that may affect system performance include:

Flexible Label Application

The Al Code can be configured for a variety of label positions and product orientations. Depending on the applicator selected, labels can be applied to different surfaces and locations.

Applications may include:

• Top labeling
• Side labeling
• Front labeling
• Back labeling
• Corner labeling
• Recessed areas
• Moving products
• Stationary products

This makes the ALcode a flexible platform for companies that require more than a standard, fixed-position label applicator.

Large Label Roll Capacity

The standard Al Code configuration supports a 300 mm label roll diameter, with larger-capacity configurations available. A larger media capacity can help reduce the frequency of label roll changes and minimize interruptions during extended production runs.

IBC can also help specify the appropriate label materials and thermal-transfer ribbons for your application.

Available consumables can include:

• Paper labels
• Synthetic labels
• Custom labels
• Preprinted labels
• Thermal-transfer labels
• Specialty labels
• Durable industrial labels
• Thermal-transfer ribbons

Product Detection & Automated Operation

The system can use sensors and control equipment to detect products and trigger the print-and-apply process at the appropriate time.

The current IBC configuration includes a product-detection photocell, while the overall system can be configured with additional components depending on the application.

Optional technologies can include:

• Product sensors
• Barcode scanners
• Label presence sensors
• Near-end-of-roll monitoring
• Air-pressure monitoring
• Production-line interfaces
• PLC integration
• Product transfer systems

Barcode Verification & Inspection

For applications where label accuracy is particularly important, the ALcode can be configured with verification technologies to help confirm label presence and barcode readability.

A laser scanner or other appropriate verification technology can be incorporated into the labeling process depending on the application.

A potential automated workflow could include:

Detect Product → Print Label → Apply Label → Verify Barcode → Confirm Application

This approach can provide an additional layer of quality control for applications involving traceability, regulated products, shipping, or serialized identification.

A Complete Print & Apply Solution

IBC can provide more than the printer applicator itself. Our team can help evaluate the complete application and recommend the technology required to build an effective automated labeling solution.

Services can include:

• Application consultation
• Production-line assessment
• Printer applicator configuration
• Custom label design
• Label material selection
• Thermal-transfer ribbon selection
• Automation integration
• Barcode design
• Barcode verification
• Conveyor integration
• Software integration
• Installation and commissioning
• Operator training
• Service and support

Al Code Printer Applicator Standard Configuration

The configuration currently listed by IBC includes:

• ALcode industrial labeling head
• Product-detection photocell
• 300 mm label unwind unit
• Multi-format swinging-arm label applicator
• Cross-rod mounting bracket
• Floor stand with mounting column

Printer and communication components can be selected based on the requirements of the final system configuration.

Why Choose the Al Code Printer Applicator?

Flexible Application Methods — Multiple pneumatic applicator configurations for different products and production environments.

Real-Time Printing — Print variable information as products move through the production process.

Industrial Performance — Designed for automated industrial labeling environments.

High-Speed Capability — Configurations can support up to approximately 100 labels per minute, depending on the application.

Custom Integration — Configure the system around your production line and product requirements.

Traceability Ready — Print barcodes, serialized information, lot numbers, dates, and other variable data.

Complete Solution Support — IBC can provide equipment, labels, ribbons, integration, installation, and ongoing support.

Automate Your Product Labeling with Al Code

The Al Code Printer Applicator provides a flexible platform for companies looking to automate the printing and application of product identification labels.

From a simple barcode label to a fully integrated automated traceability system, IBC can help configure an Al Code solution around your specific production requirements.

Looking for a flexible print-and-apply labeling system? Contact IBC to discuss your products, label requirements, production speed, and automation goals.
